Diesel Articulating Boom Lifts for Sale

Introduction to Diesel Articulating Boom Lift

Jovoo diesel articulating boom lifts give you the extra reach you need to work over and around obstacles on the job site. They offer exceptional outreach, high capacity, versatile performance and easy maintenance. The larger work envelope on an articulating lift provides you with access to those hard-to-reach places. With 20-38 meters platform height, users can easily finish high and difficult aerial jobs with Jovoo boom lift machines.

An outstanding advantage of diesel powered boom lift is that it can adapt to specific work environments, such as damp, strong corrosive, dusty, high temperature, or low temperature environments. Also, one worker can easily operate the machine with the technology-based platform control system, markedly improving work efficiency and saving time. Any special requirements, please contact Jovoo lift expert to discuss a custom solution.

Diesel Articulating Boom Lift Advantages:

  • Powerful diesel engine provides a longer work time;
  • Strong load capacity of up to 480kg;
  • Flexible turning ability to ensure smooth movement;
  • Excellent off-road performance to adapt to multiple terrains.

Diesel Articulating Boom Lift Models and Parameters

ModelV14DV16DV18DV20D
Max Working Height16m18m20.1m22.1m
Max Platform Height14m16m18.1m20.1m
Max Spanning Height7.4m7.6m8.1m9.2m
Max Operating Radius8.22m9m11.3m12m
Platform Dimensions (L*W)1.4×0.76m1.4×0.76m1.8×0.76m1.8×0.76m
Machine Length (Stowed)6.69m6.69m8.40m8.40m
Machine Width (Stowed)2.26m2.26m2.35m2.4m
Machine Height (Stowed)2.13m2.13m2.40m2.50m
Wheel Base2.10m2.10m2.5m2.5m
Ground Clearance (Center)0.41m0.41m0.3m0.32m
Machine Weight6800kg7200kg9600kg10100kg
Load Capacity230kg230kg230kg/350kg
230kg/350kg
Platform occupancy222/32/3
Jib rotation±70°±70°±70°±70°
Platform rotation160°160°160°160°
Turntable rotation360°continuous360°continuous360°continuous360°continuous
Platform levelingAutomatic LevelingAutomatic LevelingAutomatic LevelingAutomatic Leveling
Drive speed(stowed)5.5km/h5.5km/h5.2km/h5km/h
Drive speed(extended)0.8 km/h0.8km/h0.8km/h0.8km/h
Drive gradeability45%45%45%45%
Turning radius (inside)≤2.00m≤2.00m≤2.3m≤2.1m
Turning radius (outside)≤4.5m≤4.5m≤5m≤5m
Drive & steer mode4×24×24×24×2
Tire type33×1233×12355/55D625355/55D625
EngineKUBOTA /YANMARKUBOTA /YANMARKUBOTA /YANMARKUBOTA /YANMAR
Power36.5kw/3000rpm36.5kw/3000rpm36.5kw/3000rpm36.5kw/3000rpm
Fuel tank volume150L150L240L240L
Hydraulic oil tank capacity85L85L90L90L
Control voltage12V DC12V DC12V DC12V DC
