Self-Propelled Single Mast Vertical Lift for Sale

Self-Propelled Single Mast Vertical Lift for Sale

The Self-Propelled Single Mast Vertical Lift is an innovative and versatile piece of equipment that has revolutionized the way we approach vertical access in various industries. This cutting-edge machinery combines the functionality of a traditional vertical lift with the added convenience of self-propulsion, making it an ideal choice for a wide range of applications.

Designed to provide safe and efficient access to elevated areas, the Self-Propelled Single Mast Vertical Lift boasts a single mast structure that offers stability and flexibility. Its compact size and lightweight design make it easy to maneuver in tight spaces, allowing operators to navigate through narrow aisles, doorways, and other confined areas with ease.

Equipped with advanced technology, this lift is capable of reaching impressive heights, providing access to elevated work areas that were previously challenging to reach. Its self-propulsion feature eliminates the need for external power sources or manual pushing, enabling operators to move effortlessly from one location to another. This not only saves time but also enhances productivity on the job site.

Safety is a top priority when it comes to working at heights, and the Self-Propelled Single Mast Vertical Lift is designed with this in mind. It is equipped with various safety features, including emergency stop buttons, non-slip platforms, and guardrails, ensuring the well-being of operators during operation. Additionally, its intuitive controls and user-friendly interface make it easy for operators to operate the lift confidently and efficiently.

Features

  1. Proportional controls
  2. Automatic pothole protection
  3. Drivable at full height
  4. Non-marking tires
  5. Automatic brake system
  6. Emergency stop/lowering button
  7. Explosion-proof cylinders
  8. On-board diagnostic system

Self-Propelled Single Mast Vertical Lift Models and Parameters

ModelsTAM0.1-6STAM0.1-7.5S
Max Working Height8m9.5m
Max Platform Height6m7.5m
Platform Capacity150kg125kg
Occupants11
Platform Dimension (L*W)0.66m*0.67m0.66m*0.67m
Machine Dimension (L*W*H)1.40m*0.76m*1.99m1.40m*0.76m*1.99m
Wheel Base1.07m1.07m
Turning Radius0.3m0.3m
Gradeability25%25%
Travel Speed (Stowed)3.5km/h3.5km/h
Travel Speed (Raised)0.8km/h0.8km/h
Driving Motor2x24VDC/0.5KW2x24VDC/0.5KW
Lifting Motor24VDC/1.2KW24VDC/1.2KW
Battery2x12V/100Ah2x12V/100Ah
Charger12V/15A12V/15A
Weight1120kg1190kg
